Mini Compact Excavator B&S VANGUARD 408cc 14hp Engine, 65.7″ Max. Digging Depth, 1 Ton, 2370 LBS Operating Weight, MEC10

Name: Mini Compact Excavator B&S VANGUARD 408cc 14hp Engine, 65.7" Max. Digging Depth, 1 Ton, 2370 LBS Operating Weight, MEC10
SKU: f381af64521a
Price: 9699.00 USD
Availability: InStock

$9,699.00

ENGINE Model Vanguard 25V000 Displacement 408cc No.Of Cylinders 1 Engine Output 14hp Stroke 2.638in Warranty for Engine 3-Year Bore 3.465in Fuel Tank 1.52 gal Rated speed 3600rpm Engine Oil 0.7gal TRAVEL SYSTEM Max. Travel Speed 0.75 mile/h Ground Pressure 5.1psi Maximum Traction Force 3035 lbf Gradeability – Maximum Maximum 30 degrees Ground Clearance 15.9in Operating Weight 2370lbs HYDRAULIC SYSTEM Hydraulic Oil Tank 3.96gal Max.Discharge Flow

SKU: f381af64521a Category: Mini Excavator & Attachments > Mini Excavator Tag: 1.0 Ton Mini Excavator, B&S, CROBA Brand, Mini Compact Excavator, New Products, Vangard

Description

ENGINE
Model	Vanguard 25V000	Displacement	408cc
No.Of Cylinders	1	Engine Output	14hp
Stroke	2.638in	Warranty for Engine	3-Year
Bore	3.465in	Fuel Tank	1.52 gal
Rated speed	3600rpm	Engine Oil	0.7gal
TRAVEL SYSTEM
Max. Travel Speed	0.75 mile/h	Ground Pressure	5.1psi
Maximum Traction Force	3035 lbf	Gradeability – Maximum	Maximum 30 degrees
Ground Clearance	15.9in	Operating Weight	2370lbs
HYDRAULIC SYSTEM
Hydraulic Oil Tank	3.96gal	Max.Discharge Flow	4.65 gpm
SWING SYSTEM
Swing Speed	8rpm	Tail Swing Radius	32.6in
DIGGING FORCE
Bucket Digging Force	1619 lbf	Arm Digging Force	1191 lbf
Bucket Capacity	0.7 ft³	Bucket Width	15 in
SCOPE OF WORK
Max.Digging Height	109 in	Min Turning Radius Of Working Device	48.1in
Max.Dumping Height	80 in	Max. Lifting Height Dozer Blade	5.9in
Max.Digging Depth	65.7in	Max. Depth Dozer Blade	7.4in
Max.Vertical Digging Depth	62.6in	Boom Swing – Left	53°
Max Digging Radius	119in	Boom Swing – Right	40°
Max.digging Radius At Ground Level	118.7in
DIMENSIONS
Transportation Length	82in/115in	Crawler Wheel Base	36in
Overall Width	37in	Track Belt/Shoe Width	7in
Overall Height（To Top Of Cab）	88.5in	Track Length	48.5in
Counter Weight Ground Clearance	16in	Track Width	37in
SERVICE
Package Method	Wood Case	Warranty for Machine	1 Year
Packing Size	91x40x98 in	Weight (N.W./G.W.)	2180/2440 lbs

WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
